Taw qhia
Thaum npaj ib qhov loj - qhov project teeb pom kev zoo architectural, feem ntau cov neeg yuav khoom them rau qhov ci ntsa iab, kev ntsuas dej tsis zoo, kev tswj xyuas, lossis kev teeb tsa. Cov yam tseem ceeb no yog qhov tseem ceeb, tab sis muaj lwm qhov kev ntsuas uas muaj kev cuam tshuam ntau dua rau qhov pom qhov kawg: pixel suab.
Ntau qhov project tsis xa cov kev cia siab tso saib zoo tsis yog vim qhovLED mesh npoyog qhov tsis zoo, tab sis vim qhov xaiv pixel suab tsis phim lub tsev loj, saib nrug, lossis cov ntsiab lus xav tau.
Ib qho screen nrog lub suab me me heev ua rau cov nqi tsim nyog yam tsis tau muab cov txiaj ntsig pom. Hloov pauv, lub vijtsam nrog lub suab loj dhau yuav ua rau cov duab tsis meej thiab txo qhov cuam tshuam tag nrho.
Rau cov neeg tsim khoom, cov neeg cog lus, cov tsim teeb pom kev zoo, thiab cov thawj coj ntawm kev yuav khoom, xaiv qhov tseeb LED daim phiaj qhov sib nrug yog ib qho kev txiav txim siab tseem ceeb tshaj plaws hauv kev tshaj tawm façade project.
Tom ntej no, peb yuav tsom mus rau kev piav qhia yuav ua li cas pixel ptich cuam tshuam rau kev ua tau zoo ntawm cov duab, yuav ua li cas sib npaug qhov sib txawv ntawm lub tsev sib txawv, thiab yuav ua li cas kom ua tiav qhov sib npaug zoo tshaj plaws ntawm cov duab zoo, cov nqi teeb tsa, thiab kev nqis peev ntev -.
Pixel Pitch txhais li cas hauv LED Mesh Screen?
Pixel pitch yog hais txog qhov chaw nruab nrab - mus rau - nruab nrab ntawm qhov nruab nrab ntawm cov teeb pom kev zoo ntawm LED nyob ib sab.
Tsis zoo li cov khoom siv sab hauv tsev LED uas feem ntau siv pitches hauv qab 5 hli,architectural LED mesh zaubyog tsim los rau kev saib ntev thiab yog li siv ntau qhov loj pixel pitches.
Hom sab nraum zoov saj zawg zog mesh npo pitches muaj xws li:
P31.25,P40,P50P55,P62.5,P80,P100,P125,P150
Txhua pixel ptich ua haujlwm rau lub hom phiaj sib txawv, thiab tsis muaj leej twg tuaj yeem piav qhia tias "zoo dua."
Qhov kev xaiv raug yog nyob ntawm qhov kev xav tau ntawm qhov project.
Pixel Pitch ncaj qha txiav txim qhov pom kev nthuav dav
Thawj txoj cai ntawm ib qho twgLED media facadeqhov project yog qhov yooj yim:
Qhov me me pixel suab, qhov siab dua cov duab daws teeb meem.
Ntau LEDs tau teeb tsa nyob rau hauv txhua square meter, tso cai rau lub vijtsam kom pom cov duab zoo dua, cov ntawv nyeem zoo dua, thiab siab dua -txhais video.
Qhov no ua rau me me pitches haum rau tej yaam num uas cov neeg saib lub tsev los ntawm luv luv nrug.
Txawm li cas los xij, kev daws teeb meem siab dua ib txwm los nrog cov nqi khoom siv ntau dua, kev siv hluav taws xob ntau ntxiv, thiab kev teeb tsa ntau dua.
Yog li ntawd, nrhiav lub suab me me tsis yog ib qho kev daws teeb meem zoo tshaj plaws.
Saib nrug yuav tsum ib txwm yog thawj tus qauv tsim
Ntau tus tswv qhov project xaiv pixel suab ua ntej txiav txim siab saib qhov deb.
Qhov no yog ib qho ntawm feem ntau yuam kev nyob rau hauv façade zaub tej yaam num.
Tib neeg lub qhov muag tsuas yog paub qhov txawv ib theem ntawm kev nthuav dav los ntawm ib qho kev ncua deb.
Yog tias cov neeg saib xyuas ib txwm saib lub tsev ntawm 150 meters deb, txhim kho qhov siab heev -cov ntxaij vab tshaus mesh muaj txiaj ntsig me me ntxiv.
Hloov chaw, pab pawg ua haujlwm yuav tsum xub txheeb xyuas qhov twg cov neeg saib feem ntau yuav sawv.
Tej yam xwm txheej saib muaj xws li:
● Nroog plazas
● Txoj kev loj
● Cov tsev ua haujlwm sab nraud
●Public parks
● Kev loj hlob
Thaum tus thawj saib qhov deb tau txhais, qhov tsim nyog mesh qhov sib txawv yuav yooj yim dua los txiav txim.
P31.25: Qhov Kev Xaiv Zoo Tshaj Plaws rau Kev Pom Zoo Zoo
Ntawm cov khoom vaj tsev mesh, P31.25 muab ib qho ntawm cov kev daws teeb meem siab tshaj plaws uas muaj.
Nws yog tshwj xeeb tshaj yog haum rau tej yaam num xav tau:
●High-txhais video playback
● Hom kev tshaj tawm
● Cov duab nthuav dav
● Kev lag luam xov xwm façades
Cov ntawv thov ib txwm muaj xws li:
● Khoom kim heev khw malls Commercial complexes
●Digital landmark vaj tse
● Exhibition centers
Vim tias qhov ceev ntawm LED ntau dua, P31.25 tsim cov duab smoother thiab nyeem tau ntau dua.
Nws yog ib qho kev daws teeb meem zoo tshaj plaws thaum cov neeg saib nyob ze ntawm lub tsev.
P50: Qhov Nrov Tshaj Lij Tshaj Lij ntawm Tus Nqi thiab Kev Ua Haujlwm
Rau ntau txoj haujlwm lag luam, P50 LED Mesh zaub tau dhau los ua qhov kev xaiv zoo tshaj.
Nws muaj qhov sib npaug zoo ntawm cov zaub zoo thiab qhov project pob nyiaj siv.
Piv nrog rau qhov me me, P50 txo:
● Cov nqi khoom siv
● Cov qauv hnyav
● Lub sijhawm nruab
● Kev tu tsis yooj yim
Nyob rau tib lub sijhawm, nws tseem muab cov txiaj ntsig pom pom zoo rau qhov nruab nrab thiab qhov ntev saib.
Qhov no ua rau nws haum rau:
● Chaw ua haujlwm yees
●Hotel façades
● Sib tov - siv kev txhim kho
● Kev lag luam plazas
Rau ntau qhov project thoob ntiaj teb, P50 sawv cev rau qhov zoo tshaj plaws rov qab los ntawm kev nqis peev.
P62.5 thiab P80: Tsim rau Cov Tsev Loj
Thaum lub tsev siab tshaj 100 meters nyob rau hauv qhov siab, cov neeg saib ib txwm saib lawv los ntawm ntau dua nyob deb.
Nyob rau hauv cov xwm txheej no, qhov me me pixel pitches muab me ntsis kom zoo dua.
Hloov chaw, P62.5 thiab P80 dhau los ua kev xaiv nyiaj txiag ntau dua.
Lawv muab:
● Txo nqi qhov project
● Cov pob tshab siab dua
● Tsawg cua tsis kam
● Yooj yim installation
● Cov khoom siv qis dua
Cov yam ntxwv no ua rau lawv zoo tagnrho rau cov skyscrapers thiab cov tsev loj loj.
P100 thiab P125, P150: Kev Xaiv Tswv Yim rau Super Loj Facades
Rau thaj chaw pej thuam, txuas hniav, chaw ntau pob, thiab ultra-facades loj, pixel pitches xws li P100 thiab P125, P150 feem ntau yog cov kev daws teeb meem zoo tshaj plaws.
Txawm hais tias cov duab daws teeb meem txo qis, cov tsev no tsis tshua pom los ntawm qhov ze.
Qhov zoo muaj xws li:
● Qhov pom tseeb tshaj plaws
● Tsawg tshaj qhov hnyav installation
● Tsawg cua load
● Tus nqi peev qis dua
● Kev txhim kho sai dua
Rau tej yaam num uas teeb pom kev zoo vaj tsev yog qhov tseem ceeb tshaj li ze-ntau qhov video playback, cov pitches loj no muab tus nqi zoo heev.
Tsev Qhov siab hloov Pixel Pitch xaiv
Lub tsev qhov siab yuav tsum ib txwm cuam tshuam cov khoom xaiv.
Feem ntau hais lus:
Cov vaj tse hauv qab 30 meters tau txais txiaj ntsig los ntawm cov pixel me me vim tias cov neeg taug kev tuaj yeem saib xyuas cov ntsiab lus.
Cov tsev nyob nruab nrab ntawm 30 thiab 80 meters yuav tsum muaj qhov sib npaug ntawm cov ntsiab lus thiab tus nqi.
Cov vaj tse siab tshaj 100 meters feem ntau tau txais txiaj ntsig los ntawm qhov nruab nrab lossis loj pixel qhov sib txawv vim qhov pom qhov deb nce ntxiv.
Kev sib piv pixel suab nrog lub tsev nplai tiv thaiv kev nqis peev uas tsis tsim nyog.
Cov ntsiab lus tso saib kuj cuam tshuam rau Pixel Pitch
Tsis yog txhua qhov project qhia tib hom ntsiab lus.
Yog lub tsev feem ntau qhia:
● Hom logos
● Lub tuam txhab npe
● Festival animations
● Teeb pom kev zoo
Ib lub suab loj dua feem ntau yog txaus.
Yog hais tias lub façade qhia:
● Cov yeeb yaj kiab tshaj tawm
● Kev tshaj tawm kev lag luam
●Artistic multimedia ntsiab lus
●Dynamic storytelling
Kev daws teeb meem siab dua yuav muaj nqis dua.
Xaiv qhov sib nrug raws li cov ntsiab lus tso saib ua kom cov nqi zoo dua.
Transparency yog lwm qhov kev txiav txim siab tseem ceeb
Ib qho txiaj ntsig tseem ceeb ntawm LED mesh zaub yog pob tshab.
Raws li pixel suab nce, pob tshab kuj nce.
Cov pob tshab siab dua muab ntau yam txiaj ntsig:
●Ntawm hnub ci ntau dua
● Kev pom sab hauv tsev zoo dua
● Tsawg cua tsis kam
● Txo cov qauv tsim nyog
Rau iav kab hlau rhuav phab ntsa, pob tshab feem ntau dhau los ua qhov tseem ceeb raws li cov duab zoo.
Nrhiav qhov sib npaug ntawm qhov kev daws teeb meem thiab qhib qhov rooj yog ib lub luag haujlwm tseem ceeb ntawm cov tsim teeb pom kev zoo.
Tsis txhob ntsuas Pixel Pitch ib leeg
Ntau tus neeg yuav khoom sib piv cov khoom siv tsuas yog pixel suab.
Nyob rau hauv kev muaj tiag, tag nrho cov zaub kev ua tau zoo kuj nyob ntawm:
● Brightness
● Optical lens tsim
● LED zoo
● Greyscale kev ua tau zoo
●Refresh tus nqi
● Tswj qhov system
● Calibration raug
Ib qho zoo -tsim P50 mesh npo yuav ua tau zoo dua cov khoom tsim P31.25 tsis zoo hauv cov ntawv thov vaj tsev tiag tiag.
Yog li ntawd, kev txiav txim siab ntawm kev yuav khoom yuav tsum ntsuas qhov ua tiav tag nrho tsis yog ib qho kev qhia tshwj xeeb.
Xaus
Xaiv txoj cai LED mesh npo pixel suab tsis yog hais txog kev xaiv qhov kev daws teeb meem siab tshaj plaws - nws yog hais txog kev xaiv cov kev daws teeb meem tsim nyog tshaj plaws rau qhov project.
Qhov sib nrug zoo yog nyob ntawm saib qhov deb, lub tsev loj, tso saib cov ntsiab lus, qhov yuav tsum tau muaj pob tshab, pob nyiaj siv, thiab lub sijhawm ntev - lub hom phiaj ua haujlwm.
Txawm hais tias qhov phiaj xwm siv P31.25 rau siab -txhais lus kev lag luam tawm façades, P50 rau kev sib npaug ntawm cov khoom vaj tsev, lossis P100 rau cov vaj tse loj, lub hom phiaj tseem zoo ib yam: ua tiav qhov pom kev zoo tshaj plaws nrog kev nqis peev zoo tshaj plaws.
Qhov project teeb pom kev zoo façade yeej tsis tau txhais los ntawm cov lus qhia ib leeg. Nws yog txhais los ntawm qhov zoo npaum li cas cov cuab yeej siv tau zoo sib xws nrog cov architecture, cov neeg tuaj saib, thiab cov phiaj xwm kev lag luam.
